BRAX-MATRIX-ML165-PRO

Descripción del producto

Technical data

Power handling RMS / max.	P	120 / 170 Watts
Impedance	Z	4 Ω
DC resistance	Re	3,4 Ω
Frequency response		40 Hz - 4,000 Hz
Resonance frequency	Fs	48 Hz
Mechanical Q factor	Qms	6.80
Electrical Q factor	Qes	0.50
Total Q factor	Qts	0.47
Compliance	Cms	560 μm/N
Equivalent air volume	Vas	14.6 L
Force factor	BI*	6.3 Tm
Sensitivity	SPL	91 dB @ 2.83V / 1m 88 dB @ 1W / 1m
Cone area	Sd	137 cm²
Moving mass	Mms	19.1 g
Cone material		Carbon fleece multilayer cone
Mechanical resistance	Rms	0.87 kg/s
Voice coil diameter	ø	37 mm / 1.5"
Voice coil winding height		14 mm / 0.6"
Max. linear excursion	Xlin	+/- 4.0 mm
Max. mechanical excursion	Xmax	+/- 8.0 mm
Outer diameter	ø	167 mm / 6.5"
Installation diameter	ø	143 mm / 5.6"
Installation depth		64 mm / 2.5"

Recommended installation options
a. Infinite baffle
Recommended highpass filter		50 Hz / 24 dB/Octave “Linkwitz-Riley”

b. Sealed box
Net volume		13 L
Lower limiting frequency (-3dB)		71 Hz
Recommended highpass filter		65 Hz / 24 dB/Octave “Linkwitz-Riley”

Scope of delivery

2 x High-End Woofer BRAX MATRIX ML165 PRO
1 x Drill
1 x High quality screw driver
1 x Stainless steel screws
1 x Certificate
1 x Data sheet

Enlace:

https://www.audiotec-fischer.de/en/brax/speakers/matrix-ml165-pro
