Inputs

8 x RCA / Cinch
8 x Highlevel speaker input
1 x Optical SPDIF (12 - 96 kHz)
1 x Coax SPDIF (12 - 192 kHz)
1 x Remote In

Input sensitivity

RCA / Cinch 1 - 8 Volts
Highlevel 4 - 32 Volts

Outputs

12 x RCA / Cinch
1 x Remote Out

Output voltage

8 Volts

Frequency response

10 Hz - 44,000 Hz

DSP resolution

64 Bit

DSP power

2 x 295 MHz (2.4 billion MAC operations/second)

Sampling rate

96 kHz

DSP type

2 x Audio signal processor

Signal converters

A/D: Asahi Kasei 32 Bit
D/A: Asahi Kasei 32 Bit

Signal-to-noise ratio digital input

117 dB (A-weighted)

Signal-to-noise ratio analog input

111 dB (A-weighted)

Total harmonic distortion (THD+N) digital input

< 0.0004 %

Total harmonic distortion (THD+N) analog input

< 0.0008 %

IM distortion (IMD) digital input

< 0.0015 %

IM distortion (IMD) analog input

< 0.003 %

Crosstalk

> 90 dB

Operating voltage

9.6 - 17 Volts (max. 5 sec. down to 6 Volts)

Power rating

DC 12 V ⎓ 1.1 A max.

Current draw

550 mA

Max. remote output current

500 mA

Operating temperature range

-40°C to +70°C

Additional features

HEC slot, Ground lift switch, Smart Control Port, 32 Bit CoProcessor, ADEP.3 circuit, Auto Remote switch

Dimensions (H x W x D)

40 x 177 x 170 mm /
1.58 x 6.97 x 6.69“
