Descripción del producto

REPRODUCE MÁS GRAVES EN MENOS ESPACIO CON ESTE SUBWOOFER ULTRAFINO

Quieres el rendimiento de subgraves profundo, potente y articulado por el que se reconoce a JL Audio. Pero necesitas que quepa en un espacio ridículamente estrecho. No te preocupes. Nuestro gran subwoofer TW5v2 de 13,5 pulgadas tiene todo lo que necesitas. Es el subwoofer más delgado de su clase, ya que solo requiere 67 mm (2,625 pulgadas) de profundidad y se monta con el mismo tamaño que un woofer de 12 pulgadas típico. Sonido más potente en un diseño más pequeño: todo son ventajas.

Ofrece un rendimiento de graves potente y articulado en instalaciones de espacio reducido
Aumento del 13 % en la excursión lineal con respecto al modelo anterior de subwoofers de la serie w6v3
Requisitos de volumen de carcasa extremadamente pequeños (0,8 pies cúbicos)
El marco de aleación fundida proporciona una plataforma sólida para el altavoz con una profundidad de montaje de tan solo 2,65 pulgadas
Combina mejor con una potencia de amplificación en el intervalo de 250 a 600 vatios

https://www.garmin.com/es-ES/p/1666477/pn/010-03161-00/

Sizes	13.5"
Weight	20.5 lbs (9.3 kg)
Continuous power handling (RMS)	600 W
Sensitivity (SPL @ 1 W/1 m)	2 Ω: 85.51 dB 4 Ω: 85.63 dB
Nominal impedance	2 Ω
Recommended amplifier power (RMS)	250-600 W
Cone material	Mineral-filled polypropylene
Warranty	1 year

Connections
Speaker connections	Push-button terminal

Mounting Dimensions
Frame outer diameter	Max: 14.2" (361mm) Min: 13.0" (330 mm)
Mounting depth clearance	2.625" (67 mm)
Mounting hole	12.5" (318 mm)
Bolt hole circle	13.5" (343 mm)
Motor outer diameter	6.75" (171 mm)
Driver displacement	0.052 cu ft (1.47 L)

Parameters
Free Air Resonance (FS)	2 Ω: 25.95 Hz 4 Ω: 27.61 Hz
Electrical “Q” (Qes)	2 Ω: 0.51 4 Ω: 0.553
Mechanical “Q” (Qms)	2 Ω: 10.648 4 Ω: 10.692
Total “Q” (Qts)	2 Ω: 0.479 4 Ω: 0.526
Equivalent Compliance (Vas)	2 Ω: 2.26 cu ft (64 L) 4 Ω: 2.13 cu ft (60.31 L)
One-way linear excursion (Xmax; specs are derived via one-way voice coil overhang method with no correction factors applied)	0.433" (11 mm)
Reference Efficiency (NO)	0.23%
Effective piston area (SD)	98.26 in² (0.0634 m²)
DC resistance (RE)	2 Ω: 2.100 Ω 4 Ω: 3.513 Ω

Sealed Enclosure Specifications
Wall thickness	0.75" (19 mm)
Front baffle thickness	0.75" (19 mm)
Volume (net int.)	0.80 cu ft (22.66 L)
External width (W)	19" (483 mm)
External height (H)	15" (381 mm)
External depth (D)	7.75" (197 mm)
-3 dB cutoff frequency (F3)	2 Ω: 41.18 Hz 4 Ω: 41.42 Hz
System resonance (FC)	2 Ω: 50.75 Hz 4 Ω: 52.84 Hz
System Q at resonance (QTC)	2 Ω: 0.937 4 Ω: 1.007

Additional
Additional	Port enclosure specifications are not recommended. The enclosure recommendations listed above are external dimensions which assume the use of 0.75 in (19 mm) thick material. If you are using 0.625 in (16 mm) thick material, subtract 0.25 in (6.5 mm) from each dimension. Do not use any material with a thickness of less than 0.625 in (16 mm) as this may compromise the rigidity of the enclosure. All enclosure volumes listed above are net internal volumes! Driver displacement, port displacement and brace displacement must be added to obtain the final gross internal volume. All enclosure dimensions above have already taken this into account. When using multiples in a common enclosure you will need to recalculate the enclosure and port dimensions. For assistance please contact your authorized JL Audio dealer or JL Audio Technical Support. We recommend the use of this in a bi-amplified system using high-quality satellites and a high-quality amplifier. We do not recommend the use of this with a passive crossover (coil), as this type of device will adversely affect performance. All specifications are subject to change without notice.

Additional

Port enclosure specifications are not recommended.

The enclosure recommendations listed above are external dimensions which assume the use of 0.75 in (19 mm) thick material. If you are using 0.625 in (16 mm) thick material, subtract 0.25 in (6.5 mm) from each dimension. Do not use any material with a thickness of less than 0.625 in (16 mm) as this may compromise the rigidity of the enclosure.

All enclosure volumes listed above are net internal volumes! Driver displacement, port displacement and brace displacement must be added to obtain the final gross internal volume. All enclosure dimensions above have already taken this into account.

When using multiples in a common enclosure you will need to recalculate the enclosure and port dimensions. For assistance please contact your authorized JL Audio dealer or JL Audio Technical Support.

We recommend the use of this in a bi-amplified system using high-quality satellites and a high-quality amplifier. We do not recommend the use of this with a passive crossover (coil), as this type of device will adversely affect performance.

All specifications are subject to change without notice.
